MINI Cooper S Countryman III (2023-2024) electronic power steering system Wiring diagram
This page shows the only wiring diagram for the component.electronic power steering system, which is found in the car MINI Cooper S Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic power steering system (1 of 1)
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BLK/BRN WIRE
BLK/WHT WIRE
BLU WIRE
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM ELECTRONIC SUSPENSION SYSTEM
ELECTRONIC POWER STEERING SYSTEM
ELECTRONIC SUSPENSION SYSTEM
ENGINE CONTROLS SYSTEM
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
PNK/RED WIRE
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Body control modules circuit (4 of 4) -> ELECTRONIC POWER STEERING SYSTEM
