MINI Cooper S Countryman III (2023-2024) electrochromic interior rear view mirror Wiring diagrams

ANTI-THEFT ALARM SYSTEM IND BLK WIRE BLU WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM ELECTROCHROMIC INTERIOR REAR VIEW MIRROR FRONT PASSENGER DOOR CENTRAL LOCKING BUTTON FRONT PASSENGER DOOR POWER WINDOW SWITCH FRONT PASSENGER POWER WINDOW DRIVE FRONT POWER DISTRIBUTION BOX FUEL FILLER FLAP CENTRAL LOCKING DRIVE FUSE 38 FUSE 42 GRN WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES PASSENGER OUTSIDE DOOR HANDLE ELECTRONICS REAR DRIVER'S SIDE POWER WINDOW DRIVE REAR DRIVER'S SIDE POWER WINDOW SWITCH REAR DRIVERS SIDE DOOR LOCK RED WIRE RED/GRN WIRE RED/VIO WIRE REMOTE CONTROL RECEIVER ROOF FUNCTION CENTER SIREN W/ TILT ALARM SENSOR VIO WIRE VIO/BRN WIRE WHT WIRE YEL WIRE YEL/GRN WIRE

BLU WIRE BRN WIRE BRN/BLK WIRE DRIVER'S SIDE REAR INSIDE DOOR HANDLE LIGHT ELECTROCHROMIC INTERIOR REAR VIEW MIRROR FRONT PASSENGER DOOR POCKET LIGHTING FRONT PASSENGER DOOR POCKET LIGHTING 2 GLOVE BOX LIGHT SWITCH GLOVE COMPARTMENT LIGHT GRN WIRE GRY/RED WIRE GRY/VIO WIRE INSTRUMENT ILLUMINATION CIRCUIT LUGGAGE COMPARTMENT LAMP ORG/ WIRE RAIN/LIGHT/ SOLAR CONDENSATION SENSOR RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT SPLIT DOOR LOCK TAILGATE LOCK THIRD ROW SEATS INTERIOR LIGHT TRUNK COMPARTMENT LIGHT 2 VIO/YEL WIRE W/ LED W/O LED WHT/BLU WIRE WHT/RED WIRE WHT/YEL WIRE

ANTI-THEFT ALARM SYSTEM IND BLK WIRE BLU WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM ELECTROCHROMIC INTERIOR REAR VIEW MIRROR FRONT PASSENGER DOOR CENTRAL LOCKING BUTTON FRONT PASSENGER DOOR POWER WINDOW SWITCH FRONT PASSENGER POWER WINDOW DRIVE FRONT POWER DISTRIBUTION BOX FUEL FILLER FLAP CENTRAL LOCKING DRIVE FUSE 38 FUSE 42 GRN WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES PASSENGER OUTSIDE DOOR HANDLE ELECTRONICS REAR DRIVER'S SIDE POWER WINDOW DRIVE REAR DRIVER'S SIDE POWER WINDOW SWITCH REAR DRIVERS SIDE DOOR LOCK RED WIRE RED/GRN WIRE RED/VIO WIRE REMOTE CONTROL RECEIVER ROOF FUNCTION CENTER SIREN W/ TILT ALARM SENSOR VIO WIRE VIO/BRN WIRE WHT WIRE YEL WIRE YEL/GRN WIRE
