MINI Cooper S Countryman III (2023-2024) driver's side seat adjustment switch block Wiring diagrams

This page contains all the electrical diagrams for the component. driver's side seat adjustment switch block, in which he is found in the car MINI Cooper S Countryman III (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram driver's side seat adjustment switch block (1 of 2)

Wiring diagram driver's side seat adjustment switch block for MINI Cooper S Countryman III (2023-2024)

Get access

BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/YEL WIRE DRIVER LUMBAR SUPPORT VALVE BLOCK DRIVER'S SEAT LUMBAR SUPPORT SWITCH DRIVER'S SEAT PNEUMATIC PUMP DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT PASSENGER LUMBAR SUPPORT SWITCH FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK FRONT PASSENGER SEAT PNEUMATIC PUMP FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT POWER DISTRIBUTION BOX FUSE 73 FUSE 75 HOT W/ TERMINAL RED WIRE W/ ELECTRIC SEAT ADJUSTMENT W/O ELECTRIC SEAT ADJUSTMENT

Go to component: -> Lumbar circuit -> DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK

Wiring diagram driver's side seat adjustment switch block (2 of 2)

Wiring diagram driver's side seat adjustment switch block for MINI Cooper S Countryman III (2023-2024)

Get access

BLK WIRE BLK/BRN WIRE BLU WIRE BLU/BRN WIRE BLU/YEL WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SEAT ANGLE ADJUSTMENT DRIVE UNIT DRIVER'S SEAT BACKREST ANGLE ADJUSTMENT DRIVE DRIVER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE UNIT DRIVER'S SEAT HEIGHT ADJUSTMENT DRIVE UNIT DRIVER'S SEAT MODULE DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT POWER DISTRIBUTION BOX FUSE 127 GRN WIRE GRN/BRN WIRE GRY WIRE MEMORY FUNCTION HALL SENSOR NCA WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE RELAY 2 ENERGIZED SEATS SYSTEM SERVO MOTOR WHT WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE

Go to component: -> Memory seat circuit -> DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
