MINI Cooper S Countryman III (2023-2024) driver's side rear inside door handle light Wiring diagram
This page shows the only wiring diagram for the component.driver's side rear inside door handle light, which is found in the car MINI Cooper S Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's side rear inside door handle light (1 of 1)
BLU WIRE
BRN WIRE
BRN/BLK WIRE
DRIVER'S SIDE REAR INSIDE DOOR HANDLE LIGHT
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
FRONT PASSENGER DOOR POCKET LIGHTING
FRONT PASSENGER DOOR POCKET LIGHTING 2
GLOVE BOX LIGHT SWITCH
GLOVE COMPARTMENT LIGHT
GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
INSTRUMENT ILLUMINATION CIRCUIT
LUGGAGE COMPARTMENT LAMP
ORG/ WIRE
RAIN/LIGHT/ SOLAR CONDENSATION SENSOR
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT SPLIT DOOR LOCK
TAILGATE LOCK
THIRD ROW SEATS INTERIOR LIGHT
TRUNK COMPARTMENT LIGHT 2
VIO/YEL WIRE
W/ LED
W/O LED
WHT/BLU WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component: -> Courtesy lamps circuit (2 of 4) -> DRIVER'S SIDE REAR INSIDE DOOR HANDLE LIGHT
