MINI Cooper S Countryman III (2023-2024) driver's seat lumbar support switch wiring diagram
This page shows the only wiring diagram for the component.driver's seat lumbar support switch, which is found in the car MINI Cooper S Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
driver's seat lumbar support switch wiring diagram (1 of 1)
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRN WIRE
BRN/YEL WIRE
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT LUMBAR SUPPORT SWITCH
DRIVER'S SEAT PNEUMATIC PUMP
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
FRONT PASSENGER LUMBAR SUPPORT SWITCH
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER SEAT PNEUMATIC PUMP
FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK
FRONT POWER DISTRIBUTION BOX
FUSE 73
FUSE 75
HOT W/ TERMINAL
RED WIRE
W/ ELECTRIC SEAT ADJUSTMENT
W/O ELECTRIC SEAT ADJUSTMENT
Go to component -> Lumbar circuit -> DRIVER'S SEAT LUMBAR SUPPORT SWITCH
