MINI Cooper S Countryman III (2023-2024) drive experience switch Wiring diagrams

This page contains all the electrical diagrams for the component. drive experience switch, in which he is found in the car MINI Cooper S Countryman III (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram drive experience switch (1 of 2)

Wiring diagram drive experience switch for MINI Cooper S Countryman III (2023-2024)

Get access

BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM DRIVE EXPERIENCE SWITCH FRONT POWER DISTRIBUTION BOX FUSE 37 GRN WIRE GRN/RED WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT FRONT WHEEL SPEED SENSOR LEFT PARKING BRAKE DRIVE LEFT REAR WHEEL SPEED SENSOR NCA WIRE PARKING BRAKE BUTTON RED/BRN WIRE RIGHT FRONT WHEEL SPEED SENSOR RIGHT PARKING BRAKE DRIVE RIGHT REAR WHEEL SPEED SENSOR STEERING COLUMN SWITCH CLUSTER YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE

Go to component: -> Anti-lock brakes circuit (2 of 2) -> DRIVE EXPERIENCE SWITCH

Wiring diagram drive experience switch (2 of 2)

Wiring diagram drive experience switch for MINI Cooper S Countryman III (2023-2024)

Get access

AIR CONDITIONING BLU WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DRIVE EXPERIENCE SWITCH DVD CHANGER DYNAMIC STABILITY CONTROL (DSC) FRONT INTERIOR LIGHT FRONT POWER DISTRIBUTION BOX FUSE 32 FUSE 9 GEAR INDICATOR LIGHT GRY/RED WIRE HOT AT ALL TIMES HOT W/ BI-STABLE RELAY ENERGIZED LIGHT OPERATING UNIT NCA WIRE PARKING BRAKE BUTTON RED WIRE RED/BLU WIRE RED/YEL WIRE ROOF FUNCTION CENTER YEL/BLK WIRE

Go to component: -> Instrument illumination circuit (1 of 2) -> DRIVE EXPERIENCE SWITCH
