MINI Cooper S Countryman III (2023-2024) direction ind Wiring diagram
This page shows the only wiring diagram for the component.direction ind, which is found in the car MINI Cooper S Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram direction ind (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRN WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DIRECTION IND
FRONT POWER DISTRIBUTION BOX
FUSE 35
FUSE 47
FUSE 9
GRN WIRE
GRY WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEADLIGHT BEAM THROW ADJUSTMENT DRIVE
HIGH BEAM
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT FRONTAL LIGHT ELECTRONICS
LEFT HEADLIGHT
LIGHT OPERATING UNIT
LOW BEAM
REAR FOG LIGHT
REAR FOG LIGHT 2
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HEADLIGHT
SIDE LIGHTS/ DAYTIME DRIVING LIGHTS
STEERING COLUMN SWITCH CLUSTER
W/ LED
W/O LED
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
