MINI Cooper S Countryman III (2023-2024) dashboard lighting center Wiring diagrams

This page contains all the electrical diagrams for the component. dashboard lighting center, in which he is found in the car MINI Cooper S Countryman III (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram dashboard lighting center (1 of 2)

Wiring diagram dashboard lighting center for MINI Cooper S Countryman III (2023-2024)

Get access

BLU WIRE BRN WIRE BRN/BLK WIRE DASHBOARD LIGHTING CENTER DRIVER'S DOOR CONTOUR LIGHTING DRIVER'S DOOR CONTOUR LIGHTING 2 DRIVER'S DOOR INSIDE DOOR HANDLE LIGHT DRIVER'S DOOR POCKET LIGHTING DRIVER'S DOOR POCKET LIGHTING 2 DRIVER'S SIDE REAR FOOTWELL LIGHT GRN WIRE GRY/RED WIRE INSTRUMENT ILLUMINATION CIRCUIT LEFT FRONT FOOTWELL LIGHT ORG/ WIRE PASSENGER'S SIDE REAR FOOTWELL LIGHT RED/BLU WIRE RED/BRN WIRE RIGHT FRONT FOOTWELL LIGHT WHT/BLU WIRE WHT/RED WIRE WHT/YEL WIRE

Go to component: -> Courtesy lamps circuit (4 of 4) -> DASHBOARD LIGHTING CENTER

Wiring diagram dashboard lighting center (2 of 2)

Wiring diagram dashboard lighting center for MINI Cooper S Countryman III (2023-2024)

Get access

BRN WIRE BRN/ORG WIRE BRN/YEL WIRE CENTRAL INSTRUMENT COUNTRYMAN CLUBMAN DASHBOARD LIGHTING CENTER DOOR LOCKS SYSTEM DRIVER'S DOOR CENTRAL LOCKING BUTTON DRIVER'S DOOR POCKET LIGHTING DRIVER'S DOOR POCKET LIGHTING 2 DYNAMIC STABILITY CONTROL (DSC) FRONT PASSENGER DOOR CENTRAL LOCKING BUTTON FRONT PASSENGER DOOR POCKET LIGHTING FRONT PASSENGER DOOR POCKET LIGHTING 2 FRONT PASSENGER DOOR POWER WINDOW SWITCH GRY/RED WIRE HEAD UNIT (CENTER OF DASH) PARKING BRAKE BUTTON (CLUBMAN) PASSENGER'S SIDE REAR POWER WINDOW SWITCH REAR DRIVER'S SIDE DOOR POCKET LIGHTING REAR DRIVER'S SIDE POWER WINDOW SWITCH REAR PASSENGER'S SIDE DOOR POCKET LIGHTING REFUELING BUTTON USB CHARGING PORT 4 USB CHARGING SOCKET 3 VEHICLE INTERIOR TAILGATE BUTTON

Go to component: -> Instrument illumination circuit (2 of 2) -> DASHBOARD LIGHTING CENTER
