MINI Cooper S Countryman III (2023-2024) cooper countryman Wiring diagrams

This page contains all the electrical diagrams for the component. cooper countryman, in which he is found in the car MINI Cooper S Countryman III (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram cooper countryman (1 of 2)

Wiring diagram cooper countryman for MINI Cooper S Countryman III (2023-2024)

Get access

BLK WIRE BODY DOMAIN CONTROLLER BRN WIRE BUMPER ANTENNA COMPUTER DATA LINES SYSTEM CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS CONTACT-FREE TAILGATE OPENING LOWER SENSOR CONTACT-FREE TAILGATE OPENING UPPER SENSOR COOPER COUNTRYMAN FUSE 12 GRY/BLK WIRE GRY/RED WIRE HOT W/ BI-STABLE RELAY ENERGIZED RED/VIO WIRE WHT/BLU WIRE

Go to component: -> Contact-free tailgate opening circuit -> COOPER COUNTRYMAN

Wiring diagram cooper countryman (2 of 2)

Wiring diagram cooper countryman for MINI Cooper S Countryman III (2023-2024)

Get access

BLK WIRE BLU WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/BLK WIRE COOPER COOPER CLUBMAN, COOPER COUNTRYMAN COOPER COUNTRYMAN FANFARE HORN BUTTON FUSE 9 GRY WIRE HOT W/ BI-STABLE RELAY ENERGIZED LEFT MULTI-FUNCTION STEERING COLUMN SWITCH CLUSTER LEFT SHIFT PADDLE NCA WIRE RED/YEL WIRE RIGHT SHIFT PADDLE STEERING COLUMN SWITCH CLUSTER SUBWOOFER FANFARE HORN TWEETER FANFARE HORN VIO/BLU WIRE VIO/YEL WIRE

Go to component: -> Horn circuit -> COOPER COUNTRYMAN
