MINI Cooper S Countryman III (2023-2024) cell supervision circuit 1 Wiring diagram

This page shows the only wiring diagram for the component.cell supervision circuit 1, which is found in the car MINI Cooper S Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram cell supervision circuit 1 (1 of 1)

Wiring diagram cell supervision circuit 1 for MINI Cooper S Countryman III (2023-2024)

Get access

BATTERY MANAGEMENT ELECTRONICS BLK/GRN WIRE BLK/RED WIRE BRN WIRE BRN/YEL WIRE CELL MODULE CELL MODULE 2 CELL MODULE 3 CELL MODULE 4 CELL SUPERVISION CIRCUIT 1 CELL SUPERVISION CIRCUIT 2 CELL SUPERVISION CIRCUIT 3 CELL SUPERVISION CIRCUIT 4 COMPUTER DATA LINES SYSTEM GRN/RED WIRE GRY/RED WIRE HIGH VOLTAGE BATTERY UNIT (UNDER LEFT REAR OF VEHICLE) NCA WIRE RED/BRN WIRE TO CELL MODULE 5 (DIAGRAM 11 OF 12) TO CELL SUPERVISION CIRCUIT 5 (DIAGRAM 11 OF 12) TO SAFETY BOX (DIAGRAM 11 OF 12) VIO/GRN WIRE WHT/BLU WIRE WHT/YEL WIRE

Go to component: -> Wiring diagram engine performance 1.5l turbo hybrid (12 of 12) -> CELL SUPERVISION CIRCUIT 1
