MINI Cooper S Countryman III (2023-2024) battery management electronics Wiring diagrams

This page contains all the electrical diagrams for the component. battery management electronics, in which he is found in the car MINI Cooper S Countryman III (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram battery management electronics (1 of 2)

Wiring diagram battery management electronics for MINI Cooper S Countryman III (2023-2024)

Get access

BATTERY MANAGEMENT ELECTRONICS BLK WIRE BLK/GRN WIRE BLK/RED WIRE BRN/YEL WIRE CELL MODULE 5 CELL SUPERVISION CIRCUIT 5 FROM CELL MODULE (DIAGRAM 12 OF 12) FROM CELL MODULE 4 (DIAGRAM 12 OF 12) FROM CELL SUPERVISION CIRCUIT 4 (DIAGRAM 12 OF 12) FROM HIGH VOLTAGE BATTERY UNIT (DIAGRAM 12 OF 12) FRONT POWER DISTRIBUTION BOX FUSE 100 GRY/RED WIRE HIGH VOLTAGE BATTERY UNIT (UNDER LEFT REAR OF VEHICLE) HIGH VOLTAGE BATTERY UNIT REFRIGERANT SHUTOFF VALVE HOT AT ALL TIMES NCA WIRE ORG/ WIRE RED WIRE RED/BRN WIRE SAFETY BOX TEMPERATURE SENSOR VIO/GRN WIRE

Go to component: -> Wiring diagram engine performance 1.5l turbo hybrid (11 of 12) -> BATTERY MANAGEMENT ELECTRONICS

Wiring diagram battery management electronics (2 of 2)

Wiring diagram battery management electronics for MINI Cooper S Countryman III (2023-2024)

Get access

BATTERY MANAGEMENT ELECTRONICS BLK/GRN WIRE BLK/RED WIRE BRN WIRE BRN/YEL WIRE CELL MODULE CELL MODULE 2 CELL MODULE 3 CELL MODULE 4 CELL SUPERVISION CIRCUIT 1 CELL SUPERVISION CIRCUIT 2 CELL SUPERVISION CIRCUIT 3 CELL SUPERVISION CIRCUIT 4 COMPUTER DATA LINES SYSTEM GRN/RED WIRE GRY/RED WIRE HIGH VOLTAGE BATTERY UNIT (UNDER LEFT REAR OF VEHICLE) NCA WIRE RED/BRN WIRE TO CELL MODULE 5 (DIAGRAM 11 OF 12) TO CELL SUPERVISION CIRCUIT 5 (DIAGRAM 11 OF 12) TO SAFETY BOX (DIAGRAM 11 OF 12) VIO/GRN WIRE WHT/BLU WIRE WHT/YEL WIRE

Go to component: -> Wiring diagram engine performance 1.5l turbo hybrid (12 of 12) -> BATTERY MANAGEMENT ELECTRONICS
