MINI Cooper S Countryman III (2023-2024) automatic luggage compartment lid actuation acoustic sensor Wiring diagram

This page shows the only wiring diagram for the component.automatic luggage compartment lid actuation acoustic sensor, which is found in the car MINI Cooper S Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram automatic luggage compartment lid actuation acoustic sensor (1 of 1)

Wiring diagram automatic luggage compartment lid actuation acoustic sensor for MINI Cooper S Countryman III (2023-2024)

Get access

AUTOMATIC LUGGAGE COMPARTMENT LID ACTUATION ACOUSTIC SENSOR BLK/BLU WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FRONT POWER DISTRIBUTION BOX FUSE 107 FUSE 69 FUSE 70 FUSE 96 GRN WIRE GRN/BLK WIRE GRY/BLU WIRE HKFM HOT AT ALL TIMES HOT W/ LEFT REAR LID LIFT DRIVE NCA WIRE RED WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT REAR LID LIFT DRIVE WHT WIRE WHT/BRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE

Go to component: -> Trunk & fuel door release circuit (1 of 2) -> AUTOMATIC LUGGAGE COMPARTMENT LID ACTUATION ACOUSTIC SENSOR
