MINI Cooper S Countryman II facelift (2020-2023) elctrochromic interior mirror Wiring diagram
This page shows the only wiring diagram for the component.elctrochromic interior mirror, which is found in the car MINI Cooper S Countryman II facelift (2020-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram elctrochromic interior mirror (1 of 1)
BASE PLATE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CONVENIENCE CHARGING ELECTRONICS
CONVERTIBLE TOP MODULE
DRIVER SEAT MODULE
DRIVER VEHICLE EXTERIOR MIRROR
DRIVER'S DOOR MICROWAVE SENSOR
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S SEAT HEATING ELECTRONICS
ELCTROCHROMIC INTERIOR MIRROR
ELECTRICAL DIGITAL MOTOR ELECTRONICS
ELECTRICAL MACHINE ELECTRONICS
EXCEPT CONVERTIBLE
FRONT PASSENGER SEAT HEATING ELECTRONICS
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HIGH-VOLTAGE BATTERY UNIT
NCA WIRE
PARKING MANEUVERING ASSISTANT
PASSENGER'S DOOR MICROWAVE SENSOR
PNK WIRE
PNK/BLK WIRE
RED WIRE
REMOTE CONTROL RECEIVER
ROOF FUNCTION CENTER
SIREN, TILT SENSOR
TAILGATE FUNCTION MODULE
TRAILER MODULE
TRAILER SOCKET
VIO WIRE
VIO/YEL WIRE
W/ TRAILER MODULE
W/O TERMINATING RESISTOR
W/O TRAILER MODULE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> High/low bus circuit (2 of 4) -> ELCTROCHROMIC INTERIOR MIRROR
