MINI Cooper S Clubman II facelift (2019-2024) Headlights circuit

BLK/BLU WIRE BLK/GRN WIRE BLU WIRE BLU/GRN WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DIRECTION IND FRONT POWER DISTRIBUTION BOX FUSE 35 FUSE 47 FUSE 9 GRN WIRE GRY WIRE GRY/VIO WIRE GRY/YEL WIRE HEADLIGHT BEAM THROW ADJUSTMENT DRIVE HIGH BEAM HOT AT ALL TIMES HOT W/ BI-STABLE RELAY ENERGIZED LEFT FRONTAL LIGHT ELECTRONICS LEFT HEADLIGHT LIGHT OPERATING UNIT LOW BEAM REAR FOG LIGHT REAR FOG LIGHT 2 RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT HEADLIGHT SIDE LIGHTS/ DAYTIME DRIVING LIGHTS STEERING COLUMN SWITCH CLUSTER W/ LED W/O LED WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/VIO (OR YEL/BLU) WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DAYTIME DRIVING LIGHTS DYNAMIC STABILITY CONTROL (DSC) FRONT POWER DISTRIBUTION BOX FUSE 37 FUSE 44 FUSE 62 GRN WIRE GRN/RED WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HEADLIGHT BEAM THROW ADJUSTMENT DRIVE HIGH BEAM HOT AT ALL TIMES HOT W/ TERMINAL LEFT FOG LIGHT LOW BEAM PARKING BRAKE SWITCH RAIN/LIGHT/ SOLAR CONDENSATION SENSOR RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FOG LIGHT RIGHT FRONTAL LIGHT ELECTRONICS RIGHT HEADLIGHT SIDE LAMP SIDE LIGHTS/ DAYTIME DRIVING LIGHTS VIO/YEL WIRE W/ ELECTRIC W/O ELECTRIC W/ LED W/O ELECTRIC W/ ELECTRIC W/O LED WHT/YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE
