Instrument illumination circuit for MINI Cooper S Clubman II (2015-2019)
Instrument illumination circuit (1 of 2)
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DRIVE EXPERIENCE SWITCH
DVD CHANGER
EXCEPT CONVERTIBLE CONVERTIBLE
FRONT INTERIOR LIGHT
FRONT POWER DISTRIBUTION BOX
FUSE 32
FUSE 9
GEAR INDICATOR LIGHT
GRY/RED WIRE
HEATING/ AIR CONDITIONING SYSTEM
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LIGHT OPERATING UNIT
NCA WIRE
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
ROOF FUNCTION CENTER
YEL/BLK WIRE
Instrument illumination circuit (2 of 2)
BRN WIRE
BRN/YEL WIRE
CENTRAL INSTRUMENT
CLUBMAN, HATCHBACK 5 DOOR CONVERTIBLE, HATCHBACK 3 DOOR COUNTRYMAN
DASHBOARD LIGHTING CENTER
DOOR LOCKS SYSTEM
DRIVER'S DOOR CENTRAL LOCKING BUTTON
DRIVER'S DOOR POCKET LIGHTING
DRIVER'S DOOR POCKET LIGHTING 2
DYNAMIC STABILITY CONTROL (DSC)
FRONT PASSENGER DOOR CENTRAL LOCKING BUTTON
FRONT PASSENGER DOOR POCKET LIGHTING
FRONT PASSENGER DOOR POCKET LIGHTING 2
GRY/RED WIRE
HEAD UNIT (CENTER OF DASH)
INTERIOR REAR LID BUTTON
PARKING BRAKE BUTTON (CLUBMAN)
PASSENGER'S DOOR POWER WINDOW SWITCH
PASSENGER'S SIDE REAR POWER WINDOW SWITCH
REAR DRIVER'S SIDE DOOR POCKET LIGHTING
REAR DRIVER'S SIDE POWER WINDOW SWITCH
REAR PASSENGER'S SIDE DOOR POCKET LIGHTING
