MINI Cooper S Clubman II (2015-2019) passenger's side rear entry light Wiring diagrams
This page contains all the electrical diagrams for the component. passenger's side rear entry light, in which he is found in the car MINI Cooper S Clubman II (2015-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger's side rear entry light (1 of 2)
Go to component -> Courtesy lamps circuit (3 of 4) -> PASSENGER'S SIDE REAR ENTRY LIGHT
Wiring diagram passenger's side rear entry light (2 of 2)
Go to component -> Ground distribution circuit (2 of 3) -> PASSENGER'S SIDE REAR ENTRY LIGHT
