MINI Cooper S Clubman II (2015-2019) basic version high version except countryman countryman Wiring diagram
This page shows the only wiring diagram for the component.basic version high version except countryman countryman, which is found in the car MINI Cooper S Clubman II (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram basic version high version except countryman countryman (1 of 1)
BASIC VERSION HIGH VERSION EXCEPT COUNTRYMAN COUNTRYMAN
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BRAKE LIGHT
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
DIRECTION
EXTERIOR BOOT LID BUTTON
FOG LIGHT
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/VIO WIRE
GRY/WHT (OR GRY/YEL) WIRE
GRY/WHT WIRE
GRY/YEL (OR GRY/BLU) WIRE
GRY/YEL WIRE
INDICATOR
LEFT FRONT DIRECTION INDICATOR LIGHT REPEATER
LEFT LICENSE PLATE LAMP
LEFT OUTER TAIL LIGHT
NCA WIRE
REAR
REAR FOG LIGHT
REVERSING LIGHT
RIGHT FRONT DIRECTION INDICATOR LIGHT REPEATER
RIGHT LICENSE PLATE LAMP
RIGHT OUTER TAIL LIGHT
TAIL- LIGHT
TOP LEFT REAR LIGHT
TOP RIGHT REAR LIGHT
TURN INDICATOR
Go to component: -> Exterior lamps circuit (3 of 3) -> BASIC VERSION HIGH VERSION EXCEPT COUNTRYMAN COUNTRYMAN
