MINI Cooper Countryman III (2023-2024) front passenger seat pneumatic pump Wiring diagrams

2.0L TURBO AUC SENSOR BI-STABLE RELAY BODY DOMAIN CONTROLLER BRAKE FLUID LEVEL SWITCH BRAKE LIGHT SWITCH BRN WIRE BRN/BLK WIRE CAMERA BASED DRIVER SUPPORT SYSTEMS CHRONO METER CLUBMAN COUNTRYMAN CONTROLLER (IDRIVE) DIAGNOSTIC SOCKET DIGITAL MOTOR ELECTRONICS DRIVER'S SIDE DASHBOARD DECORATIVE STRIP LIGHTING ELECTROCHROMIC INTERIOR MIRROR EXCEPT CONVERTIBLE FRONT INTERIOR LIGHT FRONT PASSENGER DOOR ENTRY LIGHTING FRONT PASSENGER DOOR GROUND LIGHTS FRONT PASSENGER DOOR POCKET LIGHTING FRONT PASSENGER DOOR POCKET LIGHTING 2 FRONT PASSENGER DOOR TRIM PANEL LIGHTING FRONT PASSENGER INSIDE DOOR HANDLE LIGHT FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK FRONT PASSENGER SEAT HEATING ELECTRONICS FRONT PASSENGER SEAT PNEUMATIC PUMP FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT PASSENGER VEHICLE EXTERIOR MIRROR FRONT PASSENGER'S DOOR CONTOUR LIGHTING FRONT PASSENGER'S DOOR CONTOUR LIGHTING 2 FRONT PASSENGER'S SIDE REAR DOOR CONTOUR LIGHTING FRONT PASSENGER'S SIDE REAR DOOR TRIM PANEL LIGHTING FUSE 109 GEAR INDICATOR LIGHT GEAR SELECTOR SWITCH HEATED WINDSCREEN IGNITION COIL CYLINDER 1 IGNITION COIL CYLINDER 2 IGNITION COIL CYLINDER 3 IGNITION COIL CYLINDER 4 LEFT FRONT FOOTWELL LIGHT LEFT FRONT VANITY MIRROR LIGHT NCA WIRE PARKING MANEUVERING ASSISTANT PASSENGER'S DOOR MICROWAVE SENSOR PASSENGER'S ENTRANCE LIGHT DOOR PASSENGER'S SIDE DASHBOARD DECORATIVE STRIP LIGHTING PASSENGER'S SIDE DASHBOARD DECORATIVE STRIP LIGHTING 2 PASSENGER'S SIDE REAR COURTESY LIGHT PASSENGER'S SIDE REAR DOOR POCKET LIGHTING PASSENGER'S SIDE REAR FOOTWELL LIGHT PASSENGER'S SIDE REAR INSIDE DOOR HANDLE LIGHT PASSENGER'S SIDE REAR SILL COURTESY LIGHT RAIN/LIGHT/ SOLAR CONDENSATION SENSOR REAR INTERIOR LIGHT REAR WINDOW DEFOGGER REMOTE CONTROL RECEIVER RIGHT FRONT FOOTWELL LIGHT RIGHT FRONT VANITY MIRROR LIGHT ROOF FUNCTION CENTER SELECTOR LEVER SIREN W/ TILT ALARM SENSOR TOUCH BOX W/ LIN FUNCTION W/O LIN FUNCTION WINDSCREEN HEATED RELAY

BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/YEL WIRE DRIVER LUMBAR SUPPORT VALVE BLOCK DRIVER'S SEAT LUMBAR SUPPORT SWITCH DRIVER'S SEAT PNEUMATIC PUMP DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT PASSENGER LUMBAR SUPPORT SWITCH FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK FRONT PASSENGER SEAT PNEUMATIC PUMP FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT POWER DISTRIBUTION BOX FUSE 73 FUSE 75 HOT W/ TERMINAL RED WIRE W/ ELECTRIC SEAT ADJUSTMENT W/O ELECTRIC SEAT ADJUSTMENT
