MINI Cooper Countryman II facelift (2020-2023) w/o removable thigh suport w/ removable thigh suport Wiring diagram

This page shows the only wiring diagram for the component.w/o removable thigh suport w/ removable thigh suport, which is found in the car MINI Cooper Countryman II facelift (2020-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram w/o removable thigh suport w/ removable thigh suport (1 of 1)

Wiring diagram w/o removable thigh suport w/ removable thigh suport for MINI Cooper Countryman II facelift (2020-2023)

Get access

AIR CONDITIONING BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER THIGH SUPPORT HEATING DRIVER'S SEAT BACKREST HEATING DRIVER'S SEAT HEATING ELECTRONICS DRIVER'S SEAT SURFACE HEATING FRONT PASSENGER SEAT HEATING ELECTRONICS FRONT PASSENGER THIGH SUPPORT HEATING FRONT PASSENGER'S SEAT BACKREST HEATING FRONT PASSENGER'S SEAT CUSHION HEATING FRONT POWER DISTRIBUTION BOX FUSE 127 FUSE 128 HOT W/ NCA WIRE RED/GRN WIRE RELAY 2 ENERGIZED VIO WIRE W/O REMOVABLE THIGH SUPORT W/ REMOVABLE THIGH SUPORT WHT WIRE

Go to component: -> Heated seats circuit, w/o memory -> W/O REMOVABLE THIGH SUPORT W/ REMOVABLE THIGH SUPORT
