MINI Cooper Countryman II facelift (2020-2023) right-hand split door lock Wiring diagrams
This page contains all the electrical diagrams for the component. right-hand split door lock, in which he is found in the car MINI Cooper Countryman II facelift (2020-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right-hand split door lock (1 of 2)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/YEL (OR ORG) WIRE
BRN/YEL WIRE
FRONT PASSENGER DOOR LOCK
GRN WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HATCHBACK
NCA WIRE
ORG/ WIRE
OUTER TAILGATE BUTTON
PASSENGER'S SIDE REAR DOOR LOCK
PASSENGER'S SIDE REAR POWER WINDOW DRIVE
PASSENGER'S SIDE REAR POWER WINDOW SWITCH
RED/GRN WIRE
RED/YEL WIRE
RIGHT-HAND SPLIT DOOR LOCK
TAILGATE BUTTON ON INSIDE OF TRUNK LID
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Anti-theft & central locking circuit (3 of 3) -> RIGHT-HAND SPLIT DOOR LOCK
Wiring diagram right-hand split door lock (2 of 2)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/YEL (OR ORG) WIRE
BRN/YEL WIRE
FRONT PASSENGER DOOR LOCK
GRN WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HATCHBACK
NCA WIRE
ORG/ WIRE
OUTER TAILGATE BUTTON
PASSENGER'S SIDE REAR DOOR LOCK
PASSENGER'S SIDE REAR POWER WINDOW DRIVE
PASSENGER'S SIDE REAR POWER WINDOW SWITCH
RED/GRN WIRE
RED/YEL WIRE
RIGHT-HAND SPLIT DOOR LOCK
TAILGATE BUTTON ON INSIDE OF TRUNK LID
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power door locks circuit (3 of 3) -> RIGHT-HAND SPLIT DOOR LOCK
