MINI Cooper Countryman II facelift (2020-2023) passenger seat occupancy detector Wiring diagram
This page shows the only wiring diagram for the component.passenger seat occupancy detector, which is found in the car MINI Cooper Countryman II facelift (2020-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger seat occupancy detector (1 of 1)
ACTIVE SOUND DESIGN
BASE PLATE
BASIC HIGH
BLK WIRE
BRN (OR BRN/ORG) WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CENTER REAR SEAT BELT BUCKLE CONTACT
CENTRAL INSTRUMENT
CLUBMAN COUNTRYMAN
CONVENIENCE CHARGING ELECTRONICS
CONVENIENCE CHARGING ELECTRONICS SHIELDS
CRASH SAFETY MODULE
DRIVER SEAT POSITION SENSOR
DRIVER'S SEAT BELT BUCKLE CONTACT
ELECTRICAL MACHINE
FANFARE HORN BUTTON
FRONT PASSENGER SEAT POSITION SENSOR
FRONT PASSENGER'S SEAT BELT BUCKLE CONTACT
HEAD UNIT
HIFI AMPLIFIER
HIGH-VOLTAGE BATTERY UNIT
HIGH-VOLTAGE CHARGING SOCKET
HIGH-VOLTAGE STARTER GENERATOR
HYBRID PRESSURE REFUELING ELECTRONIC CONTROL UNIT
ID READER
LEFT MULTI-FUNCTION STEERING COLUMN SWITCH CLUSTER
LEFT REAR SEAT BELT BUCKLE CONTACT
LEFT SHIFT PADDLE
NCA WIRE
PASSENGER SEAT OCCUPANCY DETECTOR
PRESSURE FUEL TANK CONTROL MODULE
RIGHT REAR SEAT BELT BUCKLE CONTACT
RIGHT SHIFT PADDLE
STEERING COLUMN SWITCH CLUSTER
TELEMATIC COMMUNICATION BOX
TERMINATING RESISTOR 2
USB- HUB
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL/GRN WIRE
Go to component: -> Ground distribution circuit (4 of 4) -> PASSENGER SEAT OCCUPANCY DETECTOR
