MINI Cooper Countryman II facelift (2020-2023) front passenger seat position sensor Wiring diagrams
This page contains all the electrical diagrams for the component. front passenger seat position sensor, in which he is found in the car MINI Cooper Countryman II facelift (2020-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front passenger seat position sensor (1 of 2)
Go to component -> Ground distribution circuit (4 of 4) -> FRONT PASSENGER SEAT POSITION SENSOR
Wiring diagram front passenger seat position sensor (2 of 2)
Go to component -> Supplemental restraints circuit (2 of 3) -> FRONT PASSENGER SEAT POSITION SENSOR
