MINI Cooper Countryman II (2016-2020) left side front parking maneuvering assistant ultrasonic sensor Wiring diagram
This page shows the only wiring diagram for the component.left side front parking maneuvering assistant ultrasonic sensor, which is found in the car MINI Cooper Countryman II (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side front parking maneuvering assistant ultrasonic sensor (1 of 1)
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 55
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT W/
LEFT FRONT CENTER ULTRASONIC SENSOR
LEFT FRONT OUTER ULTRASONIC SENSOR
LEFT REAR CENTER ULTRASONIC SENSOR
LEFT REAR OUTER ULTRASONIC SENSOR
LEFT SIDE FRONT PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR
PARKING MANEUVERING ASSISTANT
RED WIRE
RELAY ENERGIZED
RIGHT FRONT CENTER ULTRASONIC SENSOR
RIGHT FRONT OUTER ULTRASONIC SENSOR
RIGHT REAR CENTER ULTRASONIC SENSOR
RIGHT REAR OUTER ULTRASONIC SENSOR
RIGHT SIDE FRONT PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/WHT WIRE
Go to component -> Parking assistant circuit -> LEFT SIDE FRONT PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR
