MINI Cooper Countryman II (2016-2020) lane departure warning camera Wiring diagram
This page shows the only wiring diagram for the component.lane departure warning camera, which is found in the car MINI Cooper Countryman II (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lane departure warning camera (1 of 1)
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
CAMERA BASED DRIVER SUPPORT SYSTEMS
COMPUTER DATA LINES SYSTEM
ELECTRONIC SUSPENSION SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 59
GRN WIRE
HOT W/ TERMINAL
KAFAS CAMERA HEATING
LANE DEPARTURE WARNING CAMERA
NCA WIRE
ORG/ WIRE
RED WIRE
VIO/BLU WIRE
VIO/GRN WIRE
VIO/YEL WIRE
YEL WIRE
Go to component -> Lane departure warning circuit -> LANE DEPARTURE WARNING CAMERA
