MINI Cooper Countryman II (2016-2020) front passenger's door contour lighting 2 Wiring diagram
This page shows the only wiring diagram for the component.front passenger's door contour lighting 2, which is found in the car MINI Cooper Countryman II (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's door contour lighting 2 (1 of 1)
BLU WIRE
BRN WIRE
COURTESY LIGHTING
DRIVER VEHICLE EXTERIOR MIRROR
DRIVER'S DOOR GROUND LIGHTS
DRIVER'S SIDE DASHBOARD DECORATIVE STRIP LIGHTING
DRIVER'S SIDE REAR DOOR SILL COURTESY LIGHT
DRIVER'S SIDE REAR GROUND LIGHTS
FRONT PASSENGER DOOR GROUND LIGHTS
FRONT PASSENGER DOOR INSIDE DOOR HANDLE LIGHT
FRONT PASSENGER'S DOOR CONTOUR LIGHTING
FRONT PASSENGER'S DOOR CONTOUR LIGHTING 2
GRN WIRE
GRY/VIO WIRE
ORG/ WIRE
PASSENGER SIDE REAR SILL COURTESY LIGHT
PASSENGER'S SIDE DASHBOARD DECORATIVE STRIP LIGHTING
PASSENGER'S SIDE DASHBOARD DECORATIVE STRIP LIGHTING 2
PASSENGER'S SIDE REAR COURTESY LIGHT
PASSENGER'S SIDE REAR INSIDE DOOR HANDLE LIGHT
RED/BLU WIRE
RED/BRN WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> Courtesy lamps circuit (3 of 4) -> FRONT PASSENGER'S DOOR CONTOUR LIGHTING 2
