MINI Cooper Countryman II (2016-2020) front passenger seat height adjustment drive Wiring diagram
This page shows the only wiring diagram for the component.front passenger seat height adjustment drive, which is found in the car MINI Cooper Countryman II (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger seat height adjustment drive (1 of 1)
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
FRONT PASSENGER SEAT ANGLE ADJUSTMENT DRIVE
FRONT PASSENGER SEAT BACKREST ANGLE ADJUSTMENT DRIVE
FRONT PASSENGER SEAT FORWARD/ BACKWARD SEAT ADJUSTMENT DRIVE
FRONT PASSENGER SEAT HEIGHT ADJUSTMENT DRIVE
FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK
FRONT POWER DISTRIBUTION BOX
FUSE 95
GRN/VIO WIRE
GRN/YEL WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
WHT/BLK WIRE
WHT/VIO WIRE
Go to component -> Passenger power seat circuit -> FRONT PASSENGER SEAT HEIGHT ADJUSTMENT DRIVE
