Navigation circuit, w/ base radio & active sound design for MINI Cooper Clubman II (2015-2019)

AM/ FM AERIAL BLK/VIO WIRE BLUETOOTH AERIAL BODY DOMAIN CONTROLLER BRN WIRE BRN/BLU WIRE BRN/ORG (OR BRN) WIRE BRN/ORG WIRE BRN/RED WIRE CHANGEOVER SWITCH COMPUTER DATA LINES SYSTEM DABL AERIAL FRONT POWER DISTRIBUTION BOX FUSE 61 FUSE 79 GPS AERIAL GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRY/RED WIRE HEAD UNIT (CENTER OF DASH) HEAD UNIT BASIS W/ HOT W/ TERMINAL NAVIGATION NCA WIRE RED/BRN WIRE RED/YEL WIRE REVERSING CAMERA SDARS AERIAL TELEPHONE AERIAL USB/ETHERNET VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ WIRELESS CHARGING ODDMENTS TRAY W/O WIRELESS CHARGING ODDMENTS TRAY W/O ALARM SYSTEM LED WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WIRELESS CHARGING ODDMENTS TRAY WIRELESS CHARGING ODDMENTS TRAY AERIAL AMPLIFIER YEL WIRE YEL/BRN WIRE YEL/RED WIRE

BASIC VERSION BLK/VIO WIRE BLU WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/ORG WIRE BRN/RED WIRE CENTRAL INFORMATION DISPLAY CENTRAL INSTRUMENT GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRY/RED WIRE HIGH VERSION MICROPHONE MICROPHONE 2 (W/ VOICE INPUT) (RIGHT FRONT OF HEADLINER) NCA WIRE ORG/ WIRE RED/BRN WIRE RED/VIO WIRE TELEMATIC COMMUNICATION BOX (RIGHT SIDE OF DASH) VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

ACTIVE SOUND DESIGN (BEHIND LEFT REAR TRIM PANEL) BASE PLATE FAN BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM CONTROLLER FRONT POWER DISTRIBUTION BOX FUSE 101 FUSE 51 FUSE 68 FUSE 80 FUSE 91 GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ LEFT REAR MID-RANGE SPEAKER NCA WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT WOOFER RIGHT REAR MID-RANGE SPEAKER VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ WIRELESS CHARGING ODDMENTS TRAY W/O WIRELESS CHARGING ODDMENTS TRAY WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BRN WIRE YEL/RED WIRE

AERIAL AMPLIFIER (LEFT "C" PILLAR) AERIAL AMPLIFIER 2 (RIGHT "C" PILLAR) AERIAL DIVERSITY AUX-IN CONNECTION USB CONNECTION BASE PLATE (IN CENTER CONSOLE) BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLU WIRE BRN (OR BRN/ORG) WIRE BRN WIRE CAR SHARING MODULE CENTER CONSOLE CHANGEOVER SWITCH COMPUTER DATA LINES SYSTEM EXCEPT CLUBMAN GRN WIRE HEAD UNIT (CENTER OF DASH) HEAD UNIT BASIS W/ ID READER INSTRUMENT CLUSTER CONTROL UNIT LEFT FRONT MID-RANGE SPEAKER LEFT FRONT WOOFER LEFT SIDE WINDOW AERIAL NAVIGATION NCA WIRE ORG/ WIRE REAR SPOILER AERIAL REAR-WINDOW AERIAL RED WIRE RED/BRN WIRE RED/YEL WIRE RIGHT SIDE WINDOW AERIAL USB/ETHERNET VIO WIRE WHT/GRN WIRE WHT/RED WIRE WLAN AERIAL YEL WIRE YEL/BRN WIRE YEL/RED WIRE
