Back-up lamps circuit for Mercury Villager II (1998-2002)
Back-up lamps circuit
BLK WIRE
BLU WIRE
BLU/RED WIRE
FUSE 35
FUSE JUNCTION PANEL (BEHIND DASH, LEFT OF STEERING COLUMN)
GRN WIRE
HOT AT ALL TIMES
LEFT REVERSING LAMP
LT GRN WIRE
RED WIRE
RIGHT REVERSING LAMP
TRANSAXLE CONTROL MODULE (TCM) (BEHIND INSTRUMENT CLUSTER)
TRANSMISSION RANGE (TR) SENSOR (ON TOP FRONT OF TRANSAXLE, BELOW BATTERY)
