Mercury Villager II (1998-2002) w/ air bag connected Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 SHORTING BAR CONNECTOR AIR BAG DIAG MONITOR AIR BAG INDICATOR AIR BAG DIAGNOSTIC MONITOR (BEHIND CENTER OF DASH) AIR BAG INDICATOR AIR BAG SLIDING CONTACT BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM CONVENTIONAL CLUSTER DATA LINK CONNECTOR (DLC) (PARTIAL) (BEHIND LEFT SIDE OF DASH) DRIVER AIR BAG DRIVER AIR BAG DRIVER AIR BAG UNIT ELECTRONIC CLUSTER FUSE 37 FUSE 56 GROUND GRY WIRE HOT IN RUN OR START IGNITION INSTRUMENT CLUSTER LEFT FRONT DOOR AJAR SW LEFT FRONT DOOR AJAR SWITCH (1: DOOR CLOSED) (2: DOOR OPEN) NCA WIRE ORG/ WIRE PASSENGER AIR BAG MODULE PASSSENGER AIR BAG PASSENGER AIR BAG AIR BAG DIAG MONITOR RED WIRE RED/BLU WIRE RESISTOR A RESISTOR B SHORTING BAR (FOR AIR BAG SLIDING CONTACT) SHORTING BAR FOR PASSENGER AIR BAG MODULE (W/AIR BAG CONNECTED) TO RESISTOR B) (W/AIR BAG DISCONNECTED) W/ AIR BAG CONNECTED W/ AIR BAG DISCONNECTED WHT WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
