Mercury Villager II (1998-2002) passenger side door lock actuator assembly Wiring diagrams
This page contains all the electrical diagrams for the component. passenger side door lock actuator assembly, in which he is found in the car Mercury Villager II (1998-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger side door lock actuator assembly (1 of 2)
BLK WIRE
DRIVER SIDE DOOR LOCK ACTUATOR ASSEMBLY
DRIVER SIDE KEY LOCK SWITCH
GRN/YEL WIRE
LEFT SLIDING DOOR LOCK ACTUATOR ASSEMBLY
LIFTGATE KEY LOCK SWITCH
LIFTGATE LOCK ACTUATOR ASSEMBLY
LOCK
NCA WIRE
PASSENGER SIDE DOOR LOCK ACTUATOR ASSEMBLY
PASSENGER SIDE KEY LOCK SWITCH
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT SLIDING DOOR LOCK ACTUATOR ASSEMBLY
SLIDING DOOR CONTACT ASSEMBLIES
UNLK
VIO WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Anti-theft circuit (2 of 2) -> PASSENGER SIDE DOOR LOCK ACTUATOR ASSEMBLY
Wiring diagram passenger side door lock actuator assembly (2 of 2)
BLK WIRE
DRIVER SIDE DOOR LOCK ACTUATOR ASSEMBLY
DRIVER SIDE KEY LOCK SWITCH
GRN/YEL WIRE
LEFT SLIDING DOOR LOCK ACTUATOR ASSEMBLY
LIFTGATE KEY LOCK SWITCH
LIFTGATE LOCK ACTUATOR ASSEMBLY
LOCK
NCA WIRE
PASSENGER SIDE DOOR LOCK ACTUATOR ASSEMBLY
PASSENGER SIDE KEY LOCK SWITCH
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT SLIDING DOOR LOCK ACTUATOR ASSEMBLY
SLIDING DOOR CONTACT ASSEMBLIES
UNLK
VIO WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Power door lock circuit (2 of 2) -> PASSENGER SIDE DOOR LOCK ACTUATOR ASSEMBLY
