Mercury Villager II (1998-2002) courtesy lamp control Wiring diagrams
This page contains all the electrical diagrams for the component. courtesy lamp control, in which he is found in the car Mercury Villager II (1998-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
courtesy lamp control wiring diagram (1 of 2)
BATTERY JUNCTION BOX JOINT CONNECTOR (IN BATTERY JUNCTION BOX)
BLK WIRE
BLU/ORG WIRE
BRN WIRE
BRN/WHT WIRE
CENTRAL JUNCTION BOX FUSE
COURTESY LAMP CONTROL
COURTESY LAMPS CONTROL
DOOR SWITCH INPUT
FRONT INTERIOR LAMP
GLOVE BOX LAMP)
HOT AT ALL TIMES
IGNITION KEY SWITCH (RIGHT SIDE OF LIFGATE)
IGNITION KEY SWITCH INPUT
J/C 3 (BEHIND TOP CENTER OF DASH)
LEFT FRONT DOOR AJAR SWITCH
LEFT FRONT DOOR ENTRY LAMP
LEFT FRONT FOOTWELL LAMP
LEFT LIFTGATE AJAR SWITCH
LEFT SLIDING DOOR AJAR SWITCH
LEFT SLIDING DOOR ENTRY LAMP
LEFT VANITY MIRROR LAMP
LIFTGATE LAMP
LIFTGATE SWITCH INPUT
OFF
ON ON
ORG/ WIRE
REAR INTERIOR LAMP
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT DOOR AJAR SWITCH
RIGHT FRONT DOOR ENTRY LAMP
RIGHT FRONT FOOTWELL LAMP
RIGHT LIFTGATE AJAR SWITCH
RIGHT SLIDING DOOR AJAR SWITCH
RIGHT SLIDING DOOR ENTRY LAMP
RIGHT VANITY MIRROR LAMP
SMART ENTRY CONTROL/TIMER MODULE) (BEHIND TOP CENTER OF DASH)
UNIVERSAL GARAGE DOOR OPENER
WHT WIRE
Go to component -> Courtesy lamps circuit, without reading lights -> COURTESY LAMP CONTROL
courtesy lamp control wiring diagram (2 of 2)
BATTERY JUNCTION BOX JOINT CONNECTOR (IN BATTERY JUNCTION BOX)
BLK WIRE
BLU/ORG WIRE
BRN WIRE
BRN/WHT WIRE
CENTRAL JUNCTION BOX FUSE
COURTESY LAMP CONTROL
COURTESY LAMPS CONTROL
DOOR SWITCH INPUT
FRONT READING LAMP
GLOVE BOX LAMP)
HOT AT ALL TIMES
IGNITION KEY SWITCH
IGNITION KEY SWITCH INPUT
J/C 3 (BEHIND TOP CENTER OF DASH)
LEFT FRONT DOOR AJAR SWITCH
LEFT FRONT DOOR ENTRY LAMP
LEFT FRONT FOOTWELL LAMP
LEFT LIFTGATE AJAR SWITCH
LEFT SLIDING DOOR AJAR SWITCH
LEFT SLIDING DOOR ENTRY LAMP
LEFT VANITY MIRROR LAMP
LIFTGATE LAMP
LIFTGATE SWITCH INPUT
MAP READING LAMP
ORG/ WIRE
REAR READING LAMP
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT DOOR AJAR SWITCH
RIGHT FRONT DOOR ENTRY LAMP
RIGHT FRONT FOOTWELL LAMP
RIGHT LIFTGATE AJAR SWITCH
RIGHT SLIDING DOOR AJAR SWITCH
RIGHT SLIDING DOOR ENTRY LAMP
RIGHT VANITY MIRROR LAMP
SMART ENTRY CONTROL/TIMER MODULE) (BEHIND TOP CENTER OF DASH)
UNIVERSAL GARAGE DOOR OPENER
WHT WIRE
Go to component -> Courtesy lamps circuit, with reading lights -> COURTESY LAMP CONTROL
