Mercury Tracer I (1991-1999) washer switch hi off Wiring diagram
This page shows the only wiring diagram for the component.washer switch hi off, which is found in the car Mercury Tracer I (1991-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram washer switch hi off (1 of 1)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
GND MIST INTERVAL RELAY
HOT IN RUN
I/P FUSE PANEL
INTERVAL RHEOSTAT
JOINT CONNECTOR 1
JOINT CONNECTOR 2
LO INT
MULTI- FUNCTION SWITCH
OFF
ON INT OFF LO
ORG/ WIRE
PARK
RED WIRE
RUN WIRE
SOLID STATE
WASHER SWITCH HI OFF
WIND- SHIELD WASHER PUMP MOTOR
WIND- SHIELD WIPER MOTOR
WIPER FUSE
WIPER SWITCH
Go to component -> Front wiper/washer circuit -> WASHER SWITCH HI OFF
