Mercury Tracer I (1991-1999) starter assembly ground distribution system Wiring diagram
This page shows the only wiring diagram for the component.starter assembly ground distribution system, which is found in the car Mercury Tracer I (1991-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram starter assembly ground distribution system (1 of 1)
100 OHMS
BATTERY
BLK WIRE
BLK/YEL WIRE
CHARGE INDICATOR
ENGINE COMPARTMENT FUSE BOX
FUEL INJECTION MAXI FUSE
GENERATOR
HOT IN RUN OR START
I/P FUSE PANEL
INSTRUMENT CLUSTER
MAIN MAXI FUSE
METER FUSE
NCA WIRE
STARTER ASSEMBLY GROUND DISTRIBUTION SYSTEM
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Charging circuit -> STARTER ASSEMBLY GROUND DISTRIBUTION SYSTEM
