Mercury Tracer I (1991-1999) liftgate washer switch on off Wiring diagram
This page shows the only wiring diagram for the component.liftgate washer switch on off, which is found in the car Mercury Tracer I (1991-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram liftgate washer switch on off (1 of 1)
BLK WIRE
BLU/BLK WIRE
BLU/PNK WIRE
GROUND
GROUND DISTRIBUTON SYSTEM
HOT IN RUN REAR WIPER FUSE
I/P FUSE PANEL
JOINT CONNECTOR 3 (BEHIND TOP OF LEFT COWL PANEL)
LIFTGATE WASHER PUMP MOTOR (RIGHT REAR CARGO AREA)
LIFTGATE WASHER SWITCH ON OFF
LIFTGATE WIPER MOTOR
LIFTGATE WIPER SWITCH ON
MULTI- FUNCTION SWITCH
NCA WIRE
OFF
OFF ON
ORG/ WIRE
PARK
RUN WIRE
Go to component -> Rear wiper/washer circuit -> LIFTGATE WASHER SWITCH ON OFF
