Mercury Tracer I (1991-1999) left front win- dow motor Wiring diagram
This page shows the only wiring diagram for the component.left front win- dow motor, which is found in the car Mercury Tracer I (1991-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front win- dow motor (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
HOT IN RUN POWER WINDOW FUSE
I/P FUSE PANEL
JOINT CON- NEC- TOR #1
JOINT CON- NEC- TOR 3
LEFT FRONT WIN- DOW MOTOR
LEFT REAR WIN- DOW SWITCH
LEFT REAR WINDOW MOTOR (BEHIND TOP OF LEFT COWL PANEL)
LOCK OUT SWITCH
MASTER WINDOW SWITCH
NCA WIRE
ONE TOUCH DOWN CON- TROL UNIT
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT WINDOW MOTOR
RIGHT POWER WINDOW/ DOOR LOCK SWITCH
RIGHT REAR WIN- DOW SWITCH
RIGHT REAR WINDOW MOTOR
UP DOWN
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power window circuit -> LEFT FRONT WIN- DOW MOTOR
