Awd circuit for Mercury Sable V (2007-2009)
Awd circuit
ACTIVE TORQUE CONTROL COUPLING (ATCC) SOLENOID (UNDER CENTER REAR OF VEHICLE)
ALL WHEEL DRIVE (AWD) MODULE (BEHIND RIGHT KICK PANEL)
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 34
GND SOL -
HOT AT ALL TIMES SMART JUNCTION BOX (SJB) (UNDER LEFT SIDE OF DASH) FUSE 11
HOT IN RUN OR START
HS CAN + VPWR VBATT
HS CAN+
NCA WIRE
RED WIRE
SOL +
VIO WIRE
VIO/BRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
