Shift interlock circuit for Mercury Sable V (2007-2009)
Shift interlock circuit
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE PEDAL POSITION (BPP) SWITCH (UNDER LEFT SIDE OF DASH)
BRN WIRE
BSI
ENGINE CONTROLS SYSTEM
FET
FLOOR SHIFTER
FUSE 5 FUSE 2 (UNDER LEFT SIDE OF DASH) BOO
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES BATTERY JUNCTION BOX (BJB) FUSE (LEFT SIDE OF ENGINE COMPT)
IGNITION SWITCH
KEY IN IGNITION
LOCK
MICRO -
ORG/ WIRE
RED WIRE
SMART JUNCTION BOX (SJB)
TRANSMISSION CONTROL SWITCH
TRANSMISSIONS SYSTEM
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
