Power top/sunroof circuit for Mercury Sable V (2007-2009)
Power top/sunroof circuit
1 2 3 4 5 6 7 8 9 10 GND COMMON DEL ACC AUTO OPEN B+
ACCESSORY DELAY RELAY
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CLOSE
COMMON
FUSE
HOT AT ALL TIMES
MICRO -
ORG/ WIRE
OVERHEAD CONSOLE
RED WIRE
ROOF OPENING PANEL MODULE (CENTER FRONT OF ROOF)
SMART JUNCTION BOX (SJB) (UNDER LEFT SIDE OF DASH)
TILT UP/ AUTO OPEN
VIO WIRE
VIO/BRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/ORG WIRE
