Power mirrors circuit, without heated mirrors for Mercury Sable V (2007-2009)
Power mirrors circuit, without heated mirrors
BLK WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
DOWN
DOWN UP
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE 12
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT EXTERIOR REAR VIEW MIRROR (AT MIRROR)
LEFT RIGHT
RIGHT EXTERIOR REAR VIEW MIRROR (AT MIRROR)
RIGHT LEFT
SELECT
SMART JUNCTION BOX (SJB) (UNDER LEFT SIDE OF DASH)
YEL/VIO WIRE
