Back-up lamps circuit for Mercury Sable V (2007-2009)
Back-up lamps circuit
6 8 (TAURUS, SABLE) (TAURUS X)
AUTO- DIMMING INTERIOR MIRROR UNIT
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
FUSE 26
GRN WIRE
GRN/BRN WIRE
HOT AT ALL TIMES
LEFT REAR LAMP ASSEMBLY
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE COMPT)
RED WIRE
REVERSE
REVERSING LAMPS RELAY
REVRS
REVRS LMP
RIGHT REAR LAMP ASSEMBLY
VIO WIRE
WHT WIRE
YEL WIRE
