Mercury Sable V (2007-2009) pats tx Wiring diagram
This page shows the only wiring diagram for the component.pats tx, which is found in the car Mercury Sable V (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pats tx (1 of 1)
1 2 3 4 5 VBATT
21 22 23 24 25 26 FUEL RTN
3 4 2 1 VPWR GND COMPASS MOD - COMPASS MOD +
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLK/BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
CLOCK- SPRING (IN STEERING WHEEL)
COMPUTER DATA LINES SYSTEM
ELECTRONIC COMPASS
FUEL LEVEL SENSOR (W/ SADDLE TYPE FUEL TANK) (AWD: IN FUEL TANK)
FUEL PUMP MODULE (IN FUEL TANK)
FUSE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
HOT IN RUN OR START SMART JUNCTION BOX (SJB) FUSE 29
IGNITION SWITCH
INFO
INSTRUMENT CLUSTER
KEY IN IGNITION
MS CAN - MS CAN +
NCA WIRE
PATS TX
PNK WIRE
RESET SETUP
SOUND SYSTEMS
STEERING WHEEL SWITCH
TRACTION CTRL OFF PATS RX
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VPWR FUEL LVL IN 2 FUEL LVL IN 1 FUEL RTN OIL PRESS MESSAGE SIG LOGIC GND
W/O MICROPHONE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
WIPER/WASHER SYSTEM
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> PATS TX
