Mercury Sable V (2007-2009) license lamps/ liftgate release switch Wiring diagrams
This page contains all the electrical diagrams for the component. license lamps/ liftgate release switch, in which he is found in the car Mercury Sable V (2007-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram license lamps/ liftgate release switch (1 of 2)
AUXILIARY BLOWER MOTOR RESISTOR ASSEMBLY
BLK WIRE
DECKLID LATCH ASSEMBLY
DRIVER SEAT MODULE (DSM)
DRIVER SIDE FRONT SEAT CONTROL SWITCH
FRONT DRIVER SIDE SEAT CONTROL SWITCH
HIGH MOUNTED STOPLAMP
LEFT FRONT SEAT BACK HEATER
LEFT REAR DOOR AJAR SWITCH
LEFT REAR LAMP ASSEMBLY
LEFT REAR SEAT BACK HEATER
LEFT SECOND ROW POWER FOLD SEAT MOTOR
LICENSE LAMPS/ LIFTGATE RELEASE SWITCH
LIFTGATE DRIVE MOTOR ASSEMBLY
LIFTGATE LATCH/ UNLATCH ASSEMBLY
LIFTGATE/ TRUNK MODULE (LTM)
NCA WIRE
PARKING AID MODULE (PAM)
REAR AUXILIARY FUNCTION SELECTOR SWITCH ASSEMBLY
REAR POWER POINT
REAR WINDOW DEFROST GRID
REAR WIPER MOTOR ASSEMBLY
SECOND ROW SEAT INTERIOR/ MAP ASSEMBLY
SECOND ROW SEAT INTERIOR/ MAP LAMP ASSEMBLY
SHIELD
THIRD ROW SEAT INTERIOR/ MAP LAMP ASSEMBLY
VIO WIRE
W/ POWER LIFTGATE
W/O 6-WAY POWER SEAT W/ 6-WAY POWER SEAT
WHT WIRE
Go to component -> Ground distribution circuit (3 of 4) -> LICENSE LAMPS/ LIFTGATE RELEASE SWITCH
Wiring diagram license lamps/ liftgate release switch (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 GND CINCH
BATTERY JUNCTION
BLK/BLU WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
CENTER STACK SWITCH ASSEMBLY
CHIME PINCH SENSOR RTN ENCODER RTN
CHIME RTN ENCODER 2 ENCODER 1
CINCH MOTOR
CLUTCH
CLUTCH VBATT
COMPUTER DATA LINES SYSTEM
CONSOLE OPEN/ CLOSE SW SECTOR GEAR OPEN
FUSE 14
FUSE 17
FUSE 29 BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HALL EFFECT SENSOR
HOT AT ALL TIMES
LATCH SW HALF LATCH SW FULL PAWL SW SIG
LICENSE LAMPS/ LIFTGATE RELEASE SWITCH
LIFTGATE
LIFTGATE DRIVE MOTOR ASSEMBLY (BASE OF LEFT "D" PILLAR)
LIFTGATE GLASS AJAR
LIFTGATE LATCH/ UNLATCH ASSEMBLY (RIGHT SIDE OF LIFTGATE)
LIFTGATE REL (FET)
LIFTGATE RELEASE MS CAN+ MS CAN-
LIFTGATE SW
LIFTGATE SWITCH
LIFTGATE/GLASS AJAR RH PINCH STRIP
LIFTGATE/TRUNK MODULE (LTM) (BASE OF LEFT "D" PILLAR)
MICRO -
NCA WIRE
POWER LIFTGATE CHIME (BASE OF LEFT "D" PILLAR)
SMART JUNCTION BOX (SJB)
UN CINCH VBATT MOTOR OPEN 1 MOTOR CLOSE 1
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT/BLU WIRE
YEL WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Power liftgate circuit -> LICENSE LAMPS/ LIFTGATE RELEASE SWITCH
