Mercury Sable V (2007-2009) 46 47 8 boo bps pcm rly ctrl Wiring diagram
This page shows the only wiring diagram for the component.46 47 8 boo bps pcm rly ctrl, which is found in the car Mercury Sable V (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 46 47 8 boo bps pcm rly ctrl (1 of 1)
46 47 8 BOO BPS PCM RLY CTRL
BLK/BLU WIRE
BOO
BRAKE PEDAL POSITION (BPP) SWITCH (UNDER LEFT SIDE OF DASH)
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER STACK SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
CONSOLE OPEN/ CLOSE SW
ENABLE/DISABLE
FUSE 2
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/YEL WIRE
HAZARD
HOT AT ALL TIMES
INSTRUMENT CLUSTER (IC)
IVD IND
IVD SW
LIFTGATE
LIFTGATE/TRUNK MODULE (LTM) (BASE OF LEFT "D" PILLAR)
MICRO -
MS CAN +
ORG/ WIRE
PARKING AID
POWERTRAIN CONTROL MODULE (REAR OF ENGINE COMPT)
RED WIRE
SENSOR MODULE (SASM)
SMART JUNCTION BOX (SJB) (UNDER LEFT SIDE OF DASH)
SOLID STATE
STATUS LED
TRACTION CONTROL ON/OFF
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> 46 47 8 BOO BPS PCM RLY CTRL
