Mercury Sable V (2007-2009) 1 1 1 1 dr sab rtn dr sab feed ps sab feed ps sab rtn Wiring diagram

1 1 1 1 DR SAB RTN DR SAB FEED PS SAB FEED PS SAB RTN BLK WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/WHT WIRE CLOCKSPRING (IN STEERING COLUMN) COMPUTER DATA LINES SYSTEM DR 2 RTN DR 2 FEED PS 2 FEED PS 2 RTN CAN - CAN + DR IMP SNS DR IMP SNS DRIVER AIR BAG MODULE (IN STEERING WHEEL) DRIVER SAFETY BELT BUCKLE PRETENSIONER (UNDER DRIVER'S SEAT) DRIVER SEAT SAFETY BELT LOAD LIMITING RETRACTOR (BASE OF LEFT "B" PILLAR) DRIVER SIDE IMPACT SENSOR 1 (IN DRIVER'S DOOR) GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/YEL WIRE NCA WIRE ORG/ WIRE PAD LP PASSENGER AIR BAG MODULE (BEHIND RIGHT SIDE OF DASH) PASSENGER SAFETY BELT BUCKLE PRETENSIONER (UNDER FRONT PASSENGER'S SEAT) PASSENGER SEAT SAFETY BELT LOAD LIMITING RETRACTOR (BASE OF RIGHT "B" PILLAR) PASSENGER SIDE IMPACT SENSOR 1 (IN FRONT PASSENGER'S DOOR) PS IMP SNS PS IMP SNS RED WIRE RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER CONSOLE) RIGHT FRONT IMPACT SENSOR (BEHIND RIGHT SIDE OF FRONT BUMPER) RUN/STRT VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE
