Trunk release circuit for Mercury Sable IV (1999-2005)
Trunk release circuit
BLK WIRE
CENTRAL JUNCTION BOX
FUSE 22 (UNDER LEFT SIDE OF DASH)
GENERIC ELECTRONIC MODULE (GEM) (UNDER LEFT SIDE OF DASH)
GRY/RED WIRE
HOT AT ALL TIMES
LUGGAGE COMPARTMENT LID RELEASE RELAY
LUGGAGE COMPARTMENT LID RELEASE SOLENOID (ON TRUNK LID LATCH MECHANISM)
LUGGAGE COMPARTMENT LID RELEASE SWITCH
ORG/LT GRN WIRE
PNK WIRE
PNK/ORG WIRE
RELAY CENTER BOX 2 (UNDER LEFT SIDE OF DASH)
VIO/YEL WIRE
W/ KEYLESS ENTRY
W/O KEYLESS ENTRY
YEL/LT GRN WIRE
