Starting circuit for Mercury Sable IV (1999-2005)

Starting circuit

Get access

BATTERY BATTERY JUNCTION BOX (BJB) (FRONT CENTER OF ENGINE COMPT, BEHIND RADIATOR) BATTERY JUNCTION BOX (BJB) STARTER RELAY (BEHIND RADIATOR) BLK WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX (CJB) (UNDER LEFT SIDE OF DASH) FUSE 37 FUSE B (+) IGNITION SWITCH LOCK OFF LT BLU WIRE LT GRN WIRE LT GRN/VIO WIRE NCA WIRE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RUN WIRE STARTER MOTOR TAN WIRE TAN/RED WIRE VIO WIRE WHT WIRE
