Power antenna circuit for Mercury Sable IV (1999-2005)
Power antenna circuit
BATTERY JUNCTION BOX (FRONT CENTER OF ENGINE COMPT, BEHIND RADIATOR)
BLK WIRE
BRN/PNK WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DK GRN WIRE
FUSE 26
FUSE 27
FUSE 37
HOT AT ALL TIMES
HOT IN START
NCA WIRE
POWER ANTENNA MODULE (IN LEFT SIDE OF LUGGAGE COMPARTMENT)
POWERTRAIN CONTROL MODULE (PCM)
RADIO ANTENNA
REAR CONTROL UNIT (RCU) (IN LEFT SIDE OF LUGGAGE COMPARTMENT)
RED/ORG WIRE
RED/PNK WIRE
STARTER RELAY
TAN/RED WIRE
VBATT
VPWR
