Defoggers circuit for Mercury Sable IV (1999-2005)
Defoggers circuit
AUTO A/C
BATTERY JUNCTION BOX (FRONT CENTER OF ENGINE COMPARTMENT, BEHIND RADIATOR)
BLK WIRE
BRN WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
DRIVER SIDE EXTERIOR REAR VIEW MIRROR
FUSE 11
FUSE 12
FUSE 27
FUSE 32
FUSE 7
GENERIC ELECTRONIC MODULE (GEM) (UNDER LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN
HOT IN RUN OR ACC
HOT IN START OR RUN
INTEGRATED CONTROL PANEL
LT BLU WIRE
LT GRN WIRE
MANUAL A/C
ON INDICATOR
ORG/ WIRE
PASSENGER SIDE EXTERIOR REAR VIEW MIRROR
REAR WINDOW DEFROST GRID
REAR WINDOW DEFROST RELAY 1
REAR WINDOW DEFROST RELAY 2
REAR WINDOW DEFROST SWITCH
RELAY CENTER BOX 1 (UNDER LEFT SIDE OF DASH)
RUN WIRE
SEDAN
SOLID
STATE
VIO WIRE
WAGON
WHT WIRE
YEL WIRE
