Cooling fan circuit for Mercury Sable IV (1999-2005)

Cooling fan circuit

Sable Mercury IV (1999-2005): Cooling fan circuit

Get access

86 28 46 38 91 42 VREF BATTERY JUNCTION BOX (BJB) (FRONT CENTER OF ENGINE COMPARTMENT, BEHIND RADIATOR) BLK WIRE BLK/YEL WIRE CENTRAL JUNCTION BOX (CJB) (UNDER LEFT SIDE OF DASH) DK BLU WIRE DK GRN WIRE DK GRN/ORG WIRE DUAL PRESSURE SWITCH (BEHIND A/C COMPRESSOR) ENGINE COOLING FAN BRAKE RELAY ENGINE COOLING FAN MOTOR 1 (IN FRONT OF ENGINE COMPT, BEHIND RADIATOR) ENGINE COOLING FAN MOTOR 2 (IN FRONT OF ENGINE COMPT, BEHIND RADIATOR) ENGINE COOLING FAN RELAY ENGINE COOLING FAN RESISTOR (NEAR ELECTRIC COOLING FANS) FUSE 2 FUSE 25 FUSE 9 GRY/RED WIRE HIGH SPEED FAN CONTROL RELAY HOT AT ALL TIMES HOT IN START OR RUN LOW SPEED FAN CONTROL RELAY LT BLU WIRE LT GRN/RED WIRE LT GRN/VIO WIRE LT GRN/YEL WIRE ORG/ WIRE PCM POWER RELAY RED WIRE RED/ORG WIRE RELAY CENTER BOX 1 (UNDER LEFT SIDE OF DASH) VREF SIG RTN WHT/LT BLU WIRE
