Passive anti-theft circuit for Mercury Sable IV (1999-2005)
Passive anti-theft circuit
ANTI-THEFT ``ON" INDICATOR
BATTERY JUNCTION BOX (FRONT CENTER OF ENGINE COMPT, BEHIND RADIATOR)
BLK WIRE
BLK/YEL WIRE
BRN/YEL WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) FUSE 16
DK BLU/LT GRN WIRE
FUSE 23
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
INSTRUMENT CLUSTER
MODULE (ON STEERING COLUMN, NEAR IGNITION SWITCH)
PASSIVE ANTI-THEFT TRANSCEIVER
PNK 44 30 WIRE
PNK WIRE
RED WIRE
STARTER RELAY
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
